Combined
Mains and Emergency Lighting Ballasts for Single Compact
Lamps
Features:
Combined electronic
ballast and emergency modules for compact lamps
Incorporating our Perferm™ technology
to ensure optimum operation of low mercury and amalgam construction lamps
from both 'cold start' and 'warm start' applications
The
electronic ballast circuit has a lamp failure protection circuit to
prevent damage occurring to the ballast when a lamp fails
Sine
wave output in emergency prevents unpleasant visual lamp effects and
ensures maximum lamp cathode life
Advanced
battery charging circuit exploits energy absorption charging technology
which reduces power losses in the unit, is reverse polarity protected
and provides stable charge conditions to maximise battery life
Joule combined units
have Deep Discharge Protection to further help in preventing damaging
operation conditions for the battery pack and are suitable for use with
Ni-Cad and Ni-MH cells
Designed to comply
with the requirements of the European product standards EN60924, EN 60925,
EN 60929, EN 55015, EN61000.3.2, EN 61547, EN 6134-2-7 and EN 61347-2-3
Produced
in our UK manufacturing plant which is registered and audited by BSI
to BS EN ISO 9001:2000
*'Cold
start' deemed to be temperatures above 10°C
All modules
supplied with green LED, red LED can be supplied at no extra cost
Suffix
catalogue number /RD
All products
are for 3 hours duration, for other durations, specify the required time
period e.g. P3 becomes P1 for 1 hour duration
Dimensions 180m
x 70mm x 35mm
Fixing
Centres 170mm Weight 0.54Kg
Non-Maintained
Maintained
No.
of Cells
4W
150mm
6W
225mm
7W
TC-S 4 Pin
8W
300mm
9W TC-S
4 Pin
10W
TC-D 4 Pin
11W TC-S
4 Pin
13W
TC-D 4 Pin
16W
2D 4 Pin
18W TC-D
4 Pin
28W
2D 4 Pin
38W 2D
4 Pin
PCB's for
external
gear circuits
P400/3/TL
P404/3/TL*
2x4AH
45
22
30
26
P226/3/TL
P232/3/TL*
3x4AH
45
33
33
37
28
27
24
30
20
19
PERFERM
P1028/3/TL
3x4AH
20
12
PERFERM
P1038/3/TL
5x4AH
13
* Only suitable for Switchstart circuits.
PCB suffix/T have
a fold over LED. Suffix/TL have an LED terminal block. All PCBs supplied
with a green LED.
All of the above products
are for a three hour duration, for other durations specify the required
time period e.g. for 1 hour duration change part number from /3 to /1.
